SPECS
Engine: 4-stroke, 3-cylinder, DOHC, liquid-cooled, gas
Displacement: 812cc
Bore x Stroke: 2.83×2.62 in
Compression Ratio: 9.5:1
Maximum Torque: 48.0 lb-ft @ 3500 rpm
Fuel System: DFI® with 34mm throttle body
Transmission: Continuously Variable Transmission: (CVT) with (H,L,N,R)
Final Drive: Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock
Engine Braking: Yes
Alternator Output (max): 75 amp
Front Suspension / Wheel Travel: Double wishbone/8.7 in
Rear Suspension/Wheel Travel: Double wishbone/8.5 (L) /8.7 (R) in
Front Tires: 26×9.00-12, radial
Rear Tires: 26×11.00-12, radial
Park Brake Type: Independent, Mechanical Disc
Steering: Electric Power Steering (EPS), Tilt steering
Front Brakes: Dual Disc, 2 piston caliper
Rear Brakes: Dual Disc, 1 piston caliper
Ground Clearance: 10.2 in
Fuel Capacity: 7.9 gal
Turning Radius: 16.0 ft
Cargo Bed Dimensions (LxWxH):
42.7 x 53.7 x 11.0 in (3-person), 22.0 x 53.7 x 11.0 in (6-person)
Cargo Bed Capacity: 999 lb (3-person), 350 lb (6-person)
Load Capacity: 1616.3 lb
Seating Capacity: 3-person (1 row), 6 person (2 row)
Towing Capacity: 2000 lb
Lighting: (2) Halogen headlights
Overall Length: 133.3 in
Overall Width: 64.0 in
Overall Height: 77.6 in
Curb Weight: 1911.7 lb*
Wheelbase: 92.3 in
Instruments: Multi-function display includes digital speedometer, fuel gauge, odometer, hour meter, clock, dual trip meters, 2WD/4WD indicator, water temperature warning indicator, oil pressure warning indicator, fuel injection warning indicator, CVT and EPS warning indicators, neutral, reverse and parking indicators, seatbelt reminder lamps
Wheel Type: Steel
Warranty: Kawasaki Strong 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional): 12, 24 or 36 months
