SPECIFICATIONS
Engine: 750cc four stroke, V-Twin, SOCH, liquid-cooled
Fuel System: DFI with two 36mm throttle bodies
Ignition: Digital DC-CDI
Transmission: Automatic CVT (H,L,N,R)
Final Drive: Selectable 2WD/4WD with variable control front differential lock, shaft
Front Suspension: Double wishbone; 6.7 inches of travel
Rear Suspension: Double wishbone; 7.5 inches of travel
Front Brakes: Dual hydraulic 176mm discs with 2 piston calipers
Rear Brakes: Sealed, oil bathed, multi-disc with independent part brake
Ground Clearance: 9.4 inches
Starting System: Electric
Fuel Capacity: 5.0 gallons
Electronic Power Steering (EPS)
Turning Radius: 10.5 feet
Towing Capacity: 1250 pounds
Total Rack Capacity: 242.0 pounds
Rack Capacity Front/Rear: 88.0 pounds/176.0 pounds
Lighting: 35W headlights, 5W taillight, 21W stoplight
Frame Type: Double-cradle, high tensile tubular steel
Overall Length: 86.4 inches
Overall Width: 46.5 inches
Overall Height: 48.0 inches
Seat Height: 35.8 inches
Curb Weight: 699.0 pounds
Wheelbase: 50.6 inches
Instruments:
Speedometer
Odometer
Dual trip meters
Fuel gauge
Engine Temperature
Clock
Hour meter
2WD/4WD icon
Plus indicators for EPS, Neutral, Belt and Oil Pressure
